Overview
The Chronos 4K12 high-speed camera from Kron Technologies is designed for a variety of applications, offering high performance and value. Here’s a detailed overview:
Overview
- High Resolution and Speed: It captures high-resolution images at high frame rates, suitable for slow-motion sequences.
- User Interface: Features a 5″ touchscreen for an intuitive experience.
- Output Formats: Supports RAW and compressed file outputs with fast offloading capabilities.
- Storage: Includes a 1 TB NVMe SSD for internal storage.
- Lens Mount Flexibility: Offers interchangeable lens mounts like C-Mount, E-Mount, F-Mount, EF-Mount, and MFT-Mount.
- Portability and Usability: Designed for easy use and portability, making it suitable for various environments.
Applications
- Media Production: Ideal for cinematographers and videographers, providing slow-motion footage and raw frame output.
- Sports: Useful for analyzing sports activities with clear slow-motion replays.
- Industrial and Manufacturing: Assists in troubleshooting complex problems in various industries.
- Wildlife Documentation: Captures high-frame-rate videos for wildlife studies and documentaries.
- Academic Research: Facilitates efficient data capture and analysis in research settings.
Advanced Features
- Data Management: Videos can be trimmed and transferred to the built-in SSD or external devices via dual USB-C ports.
- Connectivity Options: Includes options for gigabit Ethernet and Wi-Fi connectivity, enhancing file transfer and remote control capabilities.
Technical Capabilities
- Resolution and Frame Rates: Offers a trade-off between image resolution and frame rate, with a maximum bandwidth of approximately 12 Gigapixels per second
Highlights
- Ultra high-resolution and high-speed camera capabilities.
- Intuitive 5″ touchscreen interface.
- Flexible outputs in RAW or compressed formats.
- Built-in 1 TB NVMe SSD for storage.
- Various lens mounts available for versatility.
- Applications across media production, sports, industry, wildlife, and research.
- Advanced connectivity options including USB-C and Wi-Fi.
- Capable of handling up to 12 Gigapixels per second for detailed high-speed imaging.
FPS and Resolution 10 bit
| Resolution | 4096 x 2160 | 2048 x 2016 | 1920 x 1080 | 1280 x 1024 | 1280 x 720 | 800 x 600 | 320 x 240 | 128 x 32 |
|---|---|---|---|---|---|---|---|---|
| FPS | 1.006 | 1.082 | 1.947 | 2.060 | 2.793 | 3.316 | 6.847 | 21.231 |
FPS and Resolution 8 bit
| Resolution | 4096 x 2160 | 2048 x 2016 | 1920 x 1080 | 1280 x 1024 | 1280 x 720 | 800 x 600 | 320 x 240 | 128 x 32 |
|---|---|---|---|---|---|---|---|---|
| FPS | 1.397 | 2.065 | 3.651 | 3.856 | 5.153 | 6.059 | 11.729 | 29.002 |
Downloads
J-PRI
- 2.000 fps at 2560 x 1920
- Maximum of 32.000 fps
- 7.8 µm pixel size
- 10 Bit
- Pay-as-you-Record Options
Phantom VEO4K 590
- 4096 x 2304 with 530 fps
- 4096 x 2160 with 570fps
- 6.75 µm pixel size
- 12-bit pixel depth
- 36 GB, 72 GB high-speed internal RAM
Phantom VEO4K 990
- 4096 x 2304 with 938 fps
- 4096 x 2160 with 1.000fps
- 6.75 µm pixel size
- 12-bit pixel depth
- Global shutter (default).
