Overview
Phantom S711 High-Speed Machine Vision Camera
The Phantom S711 by Vision Research is an advanced high-speed machine vision camera designed to deliver exceptional performance and flexibility for a wide range of applications. Capable of achieving nearly 250,000 fps at reduced resolutions, the S711 supports high-speed imaging with unparalleled precision. With a maximum resolution of 1280 x 800 and a pixel size of 20 μm, this camera ensures detailed and clear imaging.
The Phantom S711 employs CoaXPress-over-Fiber (CXPoF) with CXP-12, the latest in high-speed machine vision technology, providing high throughput and ease of use with low latency data transfer. The camera also features multiple Regions of Interest (ROI) capabilities, allowing users to focus on critical parts of an event, optimize data transfer, and achieve higher frame rates.
Highlights
- Extreme High-Speed Imaging: Achieves nearly 250,000 fps at reduced resolutions.
- High Throughput: Delivers up to 7,360 fps at 1280 x 800 resolution using CoaXPress-over-Fiber (CXPoF) with CXP-12.
- Multiple ROI’s: Up to 2 flexibly located Regions-of-Interest to optimize data transfer and capture efficiency.
- Low Latency Data Transfer: Reliable data transfer with very low latency using CoaXPress-over-Fiber technology.
- Exceptional Image Quality: High image quality with low noise and high dynamic range.
- Flexible ROI Placement: Regions-of-Interest can be flexibly placed in either the top half or bottom half of the image.
- Dual Event Capture: Each ROI feeds directly to its own frame grabber, allowing the camera to capture 2 events simultaneously.
- Robust Connectivity: Includes multiple QSFP+ ports, BNC ports, and Ethernet for programming.
- Versatile Lens Mounts: Standard F Mount with optional EOS, C, M42, and PL mounts.
- Active Cooling System: Built-in active cooling with an optional Quiet mode for reduced noise operation.
- Wide Dynamic Range: Features Extreme Dynamic Range (EDR) and Auto Exposure for optimal image capture in varying lighting conditions.
- User-Friendly Design: Simple setup and easy-to-use interface for quick deployment in various applications.
- High Signal-to-Noise Ratio: Maximum SNR of 44.4 dB, ensuring clarity in captured images.
- Durable Construction: Designed to withstand operational shocks and vibrations according to MIL-STD-202H standards.
- Global Support: Supported by Vision Research’s global service network, ensuring reliable assistance and PhantomCare services.
Technical Specifications
- Sensor: CMOS with Global Shutter
- Resolution: 1280 x 800
- Pixel Size: 20 μm
- Bit Depth: 12-bit or 8-bit
- Frame Rates:
- Max Resolution: 7,360 fps (8-bit)
- 1 Megapixel: 9,850 fps (8-bit)
- Maximum: 249,080 fps (8-bit)
- Exposure: Minimum exposure of 1 μs, down to 300 ns with FAST option
- Connectivity: CoaXPress-over-Fiber (CXPoF) with CXP-12, QSFP+ ports, Ethernet
- Power: 80W 24V power supply, 16-32 VDC range
- Dimensions: 125 x 125 x 159.7 mm
- Weight: 2.4 kg
- Operating Temperature: 0 to +50˚C
- Storage Temperature: -20 to +70˚C
FPS and Resolution
Resolution | 1280 x 800 | 1024 x 720 | 1024 x 768 | 768 x 640 | 512 x 512 | 256 x 256 | 128 x 128 | 128 x 16 (1 bank) |
---|---|---|---|---|---|---|---|---|
FPS | 7.360 | 9.850 | 9.260 | 13.940 | 23.240 | 63.610 | 129.520 | 249.080 |
