Overview
The Phantom VEO-E 310L is a high-speed camera with a 3 Gpx/second capability and features a 1 Mpx sensor delivered in a 35mm format. This combination makes it an ideal choice for college and university laboratory settings, enabling researchers to utilize high-quality, easily accessible optics while achieving the required frame rates for various subjects.
Flexibility is a crucial aspect of any research tool used in academic institutions. The VEO-E camera enhances its flexibility through interchangeable lens mounts, allowing users to select the most suitable lens for each activity. Compatible lens mounts include Nikon, PL, C, and Canon EF (with electronic control), providing versatility, and switching between them is quick and effortless.
Constructed from milled aluminum, the VEO-E camera body is exceptionally lightweight and durable. As the lightest among the VEO series of cameras, the E body style weighs only 4 lbs and is designed to safeguard the camera’s most sensitive internal components. Moreover, the electronics are sealed to prevent airflow, reducing the risk of dust accumulation on the sensor.
Highlights
- 3.200 fps at full 1280 x 800 resolution
- 650.000 fps* at reduced resolutions.
- Sensitivity: Quantum Efficiency*
- Mono: 33.9%
- Color: 29.5%
- 18 or 36 RAM
- 10 µm pixel size
- Increased pixel resolution for excellent performance in laboratory research, especially microscopy and capturing small subjects with fine detail and increased magnification.
- Flexibility through interchangeable lens mounts, allowing users to choose the best lens for different activities. Compatible with Nikon, PL, C, and Canon EF (with electronic control) lenses.
- Lightweight milled aluminum construction, with the E body style weighing only 4 lbs/1.8 kg.
- 20% smaller and lighter than the core VEO models
- Effective protection of sensitive internal components by the camera’s design.
- Sealed electronics to prevent airflow and reduce the possibility of dust collecting on the sensor.
- Designed for an efficient and easy set-up with industry standard connections
- Cost-effective for laboratories and academic institutions
<sub>*Standard Model. 310L-E225 model is limited to 225,000 fps. </sub>
FPS and Resolution
Resolution | 1280 x 800 | 640 x 480 | 512 x 512 | 512 x 256 | 256 x 256 | 64 x 8 |
---|---|---|---|---|---|---|
FPS | 3.200 | 10.100 | 11.500 | 23.000 | 39.800 | 650.000* |
*Standard Model. 310L-E225 model is limited to 225,000 fps. |
