L-PRI

The L-PRI camera comes in four different configurations with a Full HD, 1920 x 1080 sensor capable to record from 1.000fps up to 3500 fps.

Overview

The L-PRI High-Speed Camera represents the pinnacle of high-speed imaging technology, offering unparalleled performance for a variety of applications. This state-of-the-art camera is equipped with a Full HD resolution of 1920 x 1080 pixels, capable of capturing astonishingly crisp and clear images at speeds of up to 3500 frames per second (fps). The versatility of the L-PRI camera is further enhanced by its range of models, each catering to different speed requirements and budgets, with models including L-PRI 1000, 1500, 2000, and 3500.


Designed for demanding scenarios, the L-PRI camera boasts a light-sensitive, high-performance CMOS sensor, offering exceptional image quality even in low-light conditions. The sensitivity of the sensor is enhanced by ISO ratings of 8000 for monochrome and 6000 for color without gain, ensuring that every detail is captured with precision.


Memory capacity is another standout feature of the L-PRI camera, with options ranging from 8GB to 128GB, ensuring ample storage for extended recording sessions. This flexibility allows for longer recording times by adjusting resolution and/or framing speed, catering to the needs of various high-speed imaging applications.


The camera also features Imaging Studio v4 Software Suite, an integral part of the camera system, which allows for easy parameterization and control. This software supports the setting of resolution, camera parameters, and includes OSD (on-screen display) with camera parameters & customer company logo.


In addition to its core capabilities, the L-PRI camera offers a range of extensions and options such as SnapOn Battery and built-in SSD, enhancing its functionality and making it a versatile tool for applications ranging from scientific research to industrial inspections and automotive crash tests.


Highlights


  • High-Speed Imaging: Up to 3500 fps at Full HD resolution (1920 x 1080 pixels).

  • Memory Options: Available in 8, 16, 32, 64, and 128 GB configurations.

  • Light Sensitive Sensor: High ISO sensitivity (8000 monochrome, 6000 color) without gain.

  • Various Models: L-PRI 1000, 1500, 2000, 3500 to suit different needs and budgets.

  • Imaging Studio v4 Software Suite: Comprehensive software for camera control and data handling.

  • Flexible Extensions: Options like SnapOn Battery and built-in SSD for enhanced functionality.

  • Robust and Portable: Ideal for both demanding laboratory environments and field applications.

  • Dynamic Range: Mono 10 Bit / Color 30 Bit, ensuring detailed image capture.

  • Customizable Settings: Adjustable exposure time and gain settings via software.


FPS and Resolution L-PRI 1000

Resolution 1920 x 1080 1920 x 900 1920 x 720 1920 x 512 1920 x 256 1920 x 128 1920 x 16
FPS 1.000 1.190 1.498 2.080 4.000 7.410 29.200

FPS and Resolution L-PRI 1500

Resolution 1920 x 1080 1920 x 900 1920 x 720 1920 x 512 1920 x 256 1920 x 128 1920 x 16
FPS 1.500 1.790 2.259 3.140 6.030 11.180 44.140

FPS and Resolution L-PRI 2000

Resolution 1920 x 1080 1920 x 900 1920 x 720 1920 x 512 1920 x 256 1920 x 128 1920 x 16
FPS 2.000 2.382 2.998 4.160 8.000 14.830 58.570

FPS and Resolution L-PRI 3500

Resolution 1920 x 1080 1920 x 900 1920 x 720 1920 x 512 1920 x 256 1920 x 128 1920 x 16
FPS 3.500 4.180 5.250 7.240 13.600 24.200 76.400
