Phantom C321 and C321J

The Phantom Miro C321J and C321 models deliver premium HD imaging suitable for in-car crash testing and various other uses. Their compact and durable design integrates seamlessly with existing Phantom imaging systems, offering enhanced versatility.

Overview

The Phantom Miro C321J and C321 cameras embody the pinnacle of high-speed imaging technology with their unparalleled HD quality, tailored for on-board auto crash testing and a multitude of other demanding applications. These cameras, known for their compactness and ruggedness, are intricately designed to function seamlessly within the broader Phantom imaging ecosystem, offering unmatched flexibility and reliability in the most challenging operational environments.


The C321J and C321 models are not just cameras; they are comprehensive imaging solutions that blend high-speed performance, durability, and sensitivity into a package that’s both user-friendly and highly adaptable. Whether it’s in a high-stakes automotive crash test or a detailed scientific study, these cameras deliver precision and quality, ensuring that no critical detail is missed.



  • High-Definition Imaging: Delivering 1920 x 1080 resolution, the cameras ensure high-quality, detailed images in all conditions.

  • Versatile Frame Rates: From 1480 fps at full resolution to a staggering 94,510 fps at minimum resolution, the cameras offer a wide range of speed options.

  • Extended Recording Capacity: The ability to store 25 shots in the 240GB Flash before downloading is ideal for repeat setups or experiments.

  • Advanced Connectivity Options: The C321J effortlessly connects to the Miro J-Box, while the C321 offers versatile connections including Ethernet and SDI for broader applications.

  • User-Oriented Features: Equipped with Image-Based Auto-Trigger, continuous recording, and programmable IO, these cameras simplify the imaging process.

  • Durable and Portable Design: Their compact size does not compromise their durability, making them perfect for mobile and field applications.

  • Specialized Imaging Tools: The cameras come with advanced features like HD-SDI, frame timestamping, and exposure control, further enhancing their utility.

  • Comprehensive Control Software: The included Phantom Camera Control software and SDK offer extensive control and customization options for various imaging needs.


Highlights


  • Exceptional Frame Rates: Achieving up to 1480 fps at full HD resolution, these cameras capture every split-second detail with impeccable clarity.

  • Quantum Efficiency for Enhanced Sensitivity: With a remarkable quantum efficiency of 45.3% in mono and 31.5% in color, the cameras excel in various lighting conditions, ensuring superior image quality.

  • Robust Build for Extreme Environments: Engineered to withstand shocks up to 170G and significant vibration levels, these cameras are built for the most demanding applications.

  • Extensive Memory Capabilities: Featuring 8 or 16 GB RAM and a substantial 240 GB internal CineFlash, the cameras are well-equipped for lengthy recording sessions without the need for frequent data transfers.

  • Innovative Data Protection: An internal battery ensures continuous operation and data protection, critical in environments where power stability is a concern.


FPS and Resolution

Resolution 1920 x 1080 1920 x 800 1280 x 1024 1280 x 720 1280 x 512 640 x 480 640 x 128 640 x 8
FPS 1.480 1.990 1.560 2.210 3.090 3.290 11.765 94.510
