Phantom VEO 1310

Capture critical moments with the Phantom VEO 1310, a top-tier, high-speed camera offering exceptional image quality and flexibility. Suitable for various applications, from military to research labs.



  • Speed: Achieving a remarkable 10,860 fps at a resolution of 1280 x 960.

  • Throughput: A powerful 13 Gpx/s allows the 1310 to capture images faster than any other VEO model.

  • Sensitivity: Exhibits high light sensitivity, with Quantum Efficiency readings of 71.6% in Mono and 53.3% in Color at standard mode.

  • Sensor: Uses a custom 1.2 Megapixel sensor with capabilities like binned mode to boost frame rates at lower resolutions.

Design and Build:

  • Build: Features a sturdy milled aluminum body that weighs approximately 5 lbs (2.3 kg) and protects the internal components from dust and sand.

  • Lensing: Comes with interchangeable lens mounts including Nikon, PL, C, and Canon EF, making it versatile for various optical needs.


  • Flexibility: Compatible with both S-model and L-model VEOs and offers advanced workflow options like a 10Gb Ethernet.

  • Binning Mode: Boosts frame rate by 25% at resolutions of 640 x 480 and below.

  • Outputs: Equipped with SDI and HDMI video outputs.

  • Special Features: These include a 10Gb Ethernet option, continuous recording, HD-SDI and HDMI video capabilities, and an innovative Image-Based Auto-Trigger.

  • Memory: Ranges from 18 GB to 72 GB of high-speed internal RAM, with CFast 2.0 cards available for S-models.

  • Exposure: Boasts a global electronic shutter, Auto Exposure, and even a Shutter Off mode for Particle Image Velocimetry (PIV).

Environmental Resilience: Designed to withstand harsh conditions with an operating temperature between -10°C and +50°C and a robust resistance against shocks and vibrations.

Connectivity and Control:

  • Control: Can be managed through On-Camera Controls on the S-model or via the Phantom Camera Control software. An SDK is also available.

  • Connectivity: Offers both standard Gb Ethernet and an optional 10Gb Ethernet for control and data downloads.


  • High-Speed Capture: Records at an astounding 10.860 fps at 1280 x 960 resolution.

  • Unrivaled Low-Light Imaging

    • A stellar temporal dark noise rating of 13.65 e-.

    • Sensitivity: Quantum Efficiency*

      • Mono: 71.6%; Binned 63.8%

      • Color: 53.3%

        *QExFF at 532nm

    • Binning Mode to elevate frame rates at diminished resolutions, ensuring optimal low-light performance

  • Flexible Design: Available in both L (light) and S (full) body styles, adaptable to varied needs.

  • Versatile Lensing: Features interchangeable mounts including Nikon, PL, C, and Canon EF.

  • Boosted Performance: Binning Mode increases frame rates by 25% at lower resolutions.

  • Advanced Outputs: Comes equipped with SDI, HDMI video outputs, and a 10Gb Ethernet option.

  • Environmental Durability: Built to endure, with a resistance to shocks, vibrations, and a temperature range from -10°C to +50°C.

  • Comprehensive Control: On-Camera Controls and Phantom Camera Control software availability, plus an SDK for customization.

  • Memory Options: From 18 GB to 72 GB of internal RAM and additional CFast 2.0 cards for S-models.

FPS and Resolution

Resolution 1280 x 960 1280 x 804 1280 x 720 960 x 960 640 x 480 320 x 240 320 x 120 320 x 12
FPS 10.860 12.900 14.350 13.333 30.030 57.360 105.260 423.350

FPS and Resolution in Binning Mode

Resolution 640 x 480 640 x 240 320 x 240 320 x 120 320 x 72 320 x 24
FPS 40.300 73.510 105.260 180.680 253.270 423.350
