Phantom VEO 610

Discover the VEO 610: A high-speed imaging marvel that combines advanced technology with practical features. Capture astounding frame rates, benefit from configurable performance, and delve into creative possibilities. Explore its versatility, durabi


Introduction: Elevating High-Speed Imaging with the Phantom VEO 610

In the dynamic landscape of high-speed imaging, the Phantom VEO 610 emerges as a significant advancement, redefining the possibilities of visual capture. This comprehensive overview delves into the impressive capabilities of the Phantom VEO 610, highlighting its features, performance, and versatile applications.

Continuity in Excellence: Building on Proven Sensor Technology

The Phantom VEO 610 stands as a testament to progress while maintaining continuity. Leveraging the same sensor technology as its predecessors, the Phantom VEO 1010 and Phantom VEO 1310, it builds upon a foundation of imaging excellence.

Impressive Frame Rates and Sensitivity: Capturing Every Detail

At the heart of the Phantom VEO 610’s capabilities lies its remarkable frame rate: an astounding 5,610 frames per second at a resolution of 1280 x 960. Its sensitivity measurements further underscore its imaging prowess:

  • Mono: 71.6% (Binned: 63.8%)

  • Color: 53.3%

Flexible Performance with Configurable RAM

Adaptability is a defining feature of the Phantom VEO 610. Its range of RAM configurations – 18GB, 36GB, and 72GB – ensures optimal performance across diverse applications, from intricate material testing to dynamic motion analysis.

Efficient Data Transfer with 10Gb Ethernet Option

Efficiency meets innovation with the 10Gb Ethernet Download Option. Seamlessly transfer data at high speeds, streamlining workflow and enabling swift analysis.

Precision Imaging with Custom Sensor Technology

The Phantom VEO 610’s custom 1.2 Megapixel sensor sets the stage for exceptional imaging. With a low temporal dark noise rating of 13.6 e-, it excels in detailed imaging, even in challenging low-light conditions.

Enhancing Creativity with Phantom Binning

Dynamic storytelling comes alive through the Phantom binning mode. Elevate frame rates and ISO levels at lower resolutions, offering creative avenues for experimentation.

Exploring Motion with a Range of Frame Rates

From capturing nuanced details to exploring dynamic motion, the Phantom VEO 610 covers a broad spectrum of frame rates. Capture scenes at over 5,610 fps at full resolution or delve into motion analysis at more than 20,800 fps at 640 x 480 resolution.

Adapting Optics with Versatile Lens Mounts

Adaptability extends to optics with multiple lens mount options: Nikon F, PL, C, and Canon EF. The VEO 610 accommodates a variety of scenarios and imaging preferences.

Durability Meets Reliability in Design

Robustness and reliability define the VEO 610’s design. With a rugged aluminum housing weighing 6 lbs (2.7 kg) and sealed components, it excels in harsh outdoor and range environments.

Key Features for Enhanced Control

Unlock creativity with key features:

  • Binning Mode: Elevate frame rates at resolutions of 640 x 480 and below.

  • Video Outputs: Flexibility through SDI and HDMI outputs.

  • S-Model Inclusions: CFast 2.0 media, 12V battery input, on-camera controls.

  • Programmable I/O: Define and assign camera signals for personalized control.

  • 10Gb Ethernet Connectivity: Swift data transfer for efficient analysis.

Redefining High-Speed Imaging

In conclusion, the Phantom VEO 610 redefines high-speed imaging by harmonizing technological advancement and practical utility. Its exceptional frame rates, sensitivity, adaptability, and reliability cater to diverse applications, from material testing to motion analysis.


  • Astounding 5,610 fps at 1280 x 960 resolution.

  • Quantum Efficiency measurements: Mono – 71.6% (Binned: 63.8%), Color – 53.3%.

  • Customizable RAM configurations: 18GB, 36GB, or 72GB.

  • Seamless 10Gb Ethernet Download Option for swift data transfer.

  • Custom 1.2 Megapixel sensor with a low temporal dark noise rating of 13.6 e-.

  • Dynamic Phantom binning mode for elevated frame rates and ISO levels.

  • Extensive range of frame rates, from full resolution to 640 x 480.

  • Versatility in lens mounts, including Nikon F, PL, C, and Canon EF.

  • Sturdy design with sealed components for unwavering reliability.

  • Key features encompass Binning Mode, Video Outputs, S-Model Inclusions, Programmable I/O, and 10Gb Ethernet Connectivity.

FPS and Resolution in Standard Mode

Resolution 1280 x 960 1280 x 804 1280 x 720 960 x 960 640 x 480 320 x 240 320 x 120 320 x 12
FPS 5.610 6.670 7.420 6.890 15.530 29.670 54.440 218.970

FPS and Resolution in Binning Mode

Resolution 640 x 480 640 x 240 320 x 240 320 x 120 320 x 72 320 x 24
FPS 20.840 38.020 54.440 93.450 131.000 218.970
