Phantom VEO4K 990

The Phantom VEO4K 990 provides the highest pixel resolution in a rugged and compact housing, available in two body styles. The S-style housing increase the flexibility by adding options for a variety of industries while still delivering highly detail

Overview

Phantom VEO4K-990 High-Speed Camera


The Phantom VEO4K-990 by Vision Research is the highest resolution camera in the VEO series, merging the compact and versatile design of the VEO with the exceptional image quality and pixel resolution of the Flex4K platform. This camera is perfect for high-speed imaging applications that require detailed object tracking, high magnification, and advanced motion analysis. The VEO4K-990 is highly configurable, featuring both global and rolling shutter modes to maximize dynamic range and imaging flexibility.


Available in both L and S body styles, the VEO4K-990 is designed to cater to a wide range of environments and requirements. The S-model provides additional on-camera controls for untethered and remote recording, ruggedized connectors, and compatibility with removable CFast 2.0 storage media, making it a robust solution for field and lab use alike.


Highlights


  • High Resolution: 9.4 Mpx resolution with 4096 x 2304 pixels.

  • High Frame Rates: Up to 938 fps at full resolution and up to 64,300 fps at reduced resolutions.

  • Versatile Shutter Options: Includes both global shutter and rolling shutter modes.

  • On-Camera Controls: Available in the S-model for untethered and remote recording.

  • Rugged Design: Built with ruggedized connectors and compatibility with CFast 2.0 storage media.

  • Exceptional Dynamic Range: Global shutter offers 54.8 dB (9 stops), while rolling shutter provides 71.6 dB (12 stops).

  • Wide Connectivity: Includes 3G-SDI, HDMI, Ethernet, and multiple programmable I/O ports.

  • Flexible Mounting Options: Standard F-Mount with optional Canon EF, PL, and C-mounts.

  • Active Cooling: Features active cooling with an optional Quiet mode for reduced noise during capture.

  • Global Support: Supported by Vision Research’s global service network, providing reliable assistance and PhantomCare services.


Technical Specifications


  • Sensor: CMOS with global and rolling shutter modes

  • Resolution: 4096 x 2304

  • Pixel Size: 6.75 μm

  • Bit Depth: 12-bit

  • Frame Rates:

    • Max Resolution: 938 fps (VEO4K-990)

    • Reduced Resolutions: Up to 64,300 fps (VEO4K-990)



  • Dynamic Range:

    • Global Shutter: 54.8 dB

    • Rolling Shutter: 71.6 dB



  • Connectivity: Gigabit Ethernet, 10Gb Ethernet optional, 3G-SDI, HDMI, multiple programmable I/O ports

  • Power: 100-240 VAC, 80W power supply, 16-32 VDC range

  • Dimensions:

    • L-Model: 127 x 127 x 150 mm

    • S-Model: 127 x 140 x 150 mm



  • Weight:

    • L-Model: 2.7 kg

    • S-Model: 3 kg



  • Operating Temperature: -10 to +50˚C

  • Storage Temperature: -20 to +70˚C


FPS and Resolution in Standard Mode

Resolution 4096 x 2304 4096 x 2160 4096 x 1152 2048 x 2048 2048 x 1152 2048 x 1080
FPS 938 1.000 1.850 1.050 1.850 1.970
